Membrane Type Filter
DFPS

Asymmetrical Polyether Sulphone Membrane Filter
Since DFPS is made of non-symmetrical polyester sulphon membrane, it can provide high porosity rate, long life and high flow rate. Desired specific resistance is obtainable by use of limited rinsing because eluted substance is very limited. DFPS is effective for such applications as ultra-pure water making and sterilization of process water.

Materials of Composition | Hardware / Polypropylene, Media / Polyether Sulphone / Support / Polypropylene, Center core / Polypropylene |
Filtration Precision (Absolute microns) | 0.04, 0.1, 0.2, 0.45, 0.65, 0.8 |
Dimensions | Outside diameter: 70mm Inside diameter: 30mm Length: 10, 20, 30, 40 (inch) / 250, 500, 750, 1000 (mm) |
Maximum Differential Pressure | 0.49MPa |
Maximum Operating Temperature | 80°C (also good for 135°C steam sterilization) |
Applicable Fluids | Ultra-pure water, Non-electrolytic plating, Chemicals, Foodstuff, Pharmaceuticals, Water for cosmetics and Alcoholic drinks |
Model Code | ![]() |
DFPY

Nylon Membrane Filter
DFPY requires no pre-treatment by use of alcohols, since it has excellent aqueous affinity. Furthermore, it offers outstanding performance in filtering organic solvents, high temperature water, alkali solutions, etc. Filters with polypropylene type hardware are also available.
Materials of Composition | Hardware / Nylon 6, Polypropylene, Media / Nylon 6 / Support / Nylon 6, Center core / Nylon 6, Polypropylene/td> |
Filtration Precision (Absolute microns) | 0.1, 0.2, 0.45, 1, 2, 4, 10 |
Dimensions | Outside diameter: 70mm Inside diameter: 30mm Length: 10, 20, 30, 40 (inch) / 250, 500, 750, 1000 (mm) |
Maximum Differential Pressure | 0.49MPa |
Maximum Operating Temperature | 80°C (also good for 135°C steam sterilization) |
Applicable Fluids | High temperature water, Pure water, Organic solvents and Alkali solutions |
Model Code | ![]() |
DFPT

Teflon Pleated Medium Filter
DFPT is suitable for handling chemicals, since polypropylene is used for support and PTFE as the medium. Designed and prepared for highly sophisticated applications, all the pieces undergo total tests prior to delivery.
Materials of Composition | Hardware /Polypropylene, Media / T: Hydrophobic PTFE H: Hydrocolloid PTFE Support / Polypropylene Center core / Polypropylene |
Filtration Precision (Absolute microns) | 0.1, 0.2, 0.45, 1, 5 |
Dimensions | Outside diameter: 70mm Inside diameter: 30mm Length: 10, 20, 30 (inch) / 250, 500, 750 (mm) |
Maximum Differential Pressure | 0.49MPa |
Maximum Operating Temperature | 80°C (also good for 135°C steam sterilization) |
Applicable Fluids | Chemicals, Photoresist, Air vent filter for tank |
Model Code | ![]() |
DFPZ

Teflon Membrane Filter
These Teflon Membrane filters are suitable for handling chemicals
Materials of Composition | Hardware /PFA Media / PTFE Support / PTFE Center core / PFA |
Filtration Precision (Absolute microns) | 0.03, 0.05, 0.1, 0.2, 0.45, 1 |
Dimensions | Outside diameter: 70mm Inside diameter: 28mm Length: 10, 20, 30 (inch) / 250, 500, 750 (mm) |
Maximum Differential Pressure | 0.49MPa |
Maximum Operating Temperature | 180°C (also good for 135°C steam sterilization) |
Applicable Fluids | Chemicals, Photoresist, Concentrated sulfuric acid, High temperature acid, Ozone water, etc |
Model Code | ![]() |
WHERE TO PLACE
- Model : DFPS
- Ultra-pure water, Non-electrolytic plating, Chemicals, Foodstuff, Pharmaceuticals, Water for cosmetics and Alcoholic drinks
- Model : DFPY
- High temperature water, Pure water, Organic solvents and Alkali solutions
- Model : DFPT
- Chemicals, Photoresist, Air vent filter for tank
- Model : DFPZ
- Chemicals, Photoresist, Concentrated sulfuric acid, High temperature acid, Ozone water, etc
